    Monitoring gate for EVT-500-R

    Code: EVT-EVB300
    Brand: ENVERTECH
    EVB GATE Primary
    €118,96
    Skladem (5 pcs)

    Detailed information

    Related products

    EVT 500R Primary
    MicroInverter 500W
    Skladem (>5 pcs)
    €130,89

    Each microinverter is individually connected to one Solar Panel. As a result, each panel is controlled by an individual Maximum Power Point Controller (MPPT). This ensures that...

    Code: EVT-500-R
    MC4 End Cap 2
    End cap for EVB cable
    Skladem (4 pcs)
    €2,35

    Original blanking end cap for Envertech EVT-500-R Microinverter cables.

    Code: BAT-EVB-CAP
    5M MC4 Primary
    Extension cable for MicroInvertor - 5m
    Skladem (4 pcs)
    €17,07

    The cable is used to connect individual Microinverters to the electrical grid. It also facilitates the connection of an entire string of inverters.

    Code: BAT-EVB-5M
    Show all related products

    Product detailed description

    The EVB300 monitoring device serves as a communication interface for microinverters and allows efficient communication with any Envertech microinverter and their direct control. Users have easy, flexible and convenient access to data and accurate analysis.

    Using the EnverPortal platform and EnverView app, you can monitor every inverter and solar module in your system. The user-friendly interface allows you to manage your solar system in real time.

    Features

    • PLCC communication (communicates over existing electrical wires)
    • Real-time monitoring via web cloud and mobile apps
    • IP48 (indoor unit)
    • Wi-Fi (802.11g/n)
    • Ability to store data on USB drive
    • Monitor up to 60 Envertech Microinverters
    • Input for 3 current sensors to measure 3 phase network (sensors not included)
    • Ethernet, RS485, USB ports

    Control and limit the power delivered

    The gateway allows you to control the maximum power of the connected solar panels and limit the overflows to the grid. At the same time, it monitors the grid frequency and adjusts the delivered power accordingly.

    Manual and automatic control can be performed.

    When current sensors are connected, the current draw from the grid can be monitored and thus directly influence the limitation of the power delivered from the Solar Panels.

    Dohledová brána k EVT-500-B Example of connecting a gateway and a microinverter.

    Web and In-App Monitoring

    Like the Microinverters themselves, the gateway uses the EnerView app (iOS and Android) and a cloud portal directly on the web. Controlling your solar power plant can be done remotely and easily on your mobile phone or computer.

    Web-based preview environment incl. DEMO preview

    Dohledová brána k EVT-500-B

    Google Play

    Android
    Dohledová brána k EVT-500-B

    App Store

    Apple iOS


    Additional parameters

    Category: Solar
    Weight: 0.34 kg
    Width: 182 mm
    Height: 100 mm
    Depth: 43 mm
    Wi-Fi: 802.11 g/n
    USB port: Yes
    RS485: Yes
    Standy By consumption: 2000 mW
    IP rating: IP40
